Tenda W308R 300Mbps Double Antenna Wireless N Router

Tenda W308R 300Mbps Double Antenna Wireless N Router
Tenda
Tenda W308R 300Mbps Double Antenna Wireless N Router
Tenda W308R is a 300mbps 802.11n compliant wireless router that delivers up to 8x faster wireless speeds and 6x farther range than 802.11g while staying backward compatible with 802.11g/ b devices. Double Antenna for secured connections. The W308R is ideal for sharing your Internet connection through out home or small office.

Price:  850

Free Downloads

Linux for Human Beings
LibreOffice.org
avast! Free Antivirus
Download Firefox — Free Web Browser
Use OpenOffice.org

Features

W308R is a 802.11n compliant wireless router that delivers up to 8x faster wireless speeds and 6x farther range than 802.11g while staying backward compatible with 802.11g devices. Connect the W308R to a cable or DSL modem and provide up to 300Mbps Internet access to multiple computers, game consoles, and media players. Create a secure wireless network to share photos, files, music, videos, printers, and network storage.

Powered by MIMO technology and equipped with two external 5dBi antennas, this router provides superior wireless coverage for larger homes and offices, or for users running bandwidth-intensive applications. The W308R also includes a 4-port 10/100Mbps Ethernet switch for extra users

With intelligent QoS, it prioritizes both wired and wireless Internet traffic to bandwidth-sensitive applications like online gaming, VoIP or stream multimedia. Also it supports for WPA/WPA2 security standards ensure that you will be able to use the best possible encryption regardless of your other wireless devices. .




N Speed
Delivers up to300Mbps wireless speed, 8X faster than ordinary wireless G devices

  Optimal Coverage
MIMO technology helps less "dead spots"to enable consistent wireless signal throughout your home

 Streaming Multimedia
Provides  wireless speed of up to 300 Mbps for streaming HD videos, simultaneous downloads, online gaming and other Internet Apps

 Secured Connection
Advanced WPA/WPA2 protects your network from intrusion

 Simply Encryption
Connect to your secure network simple and fast using WPS( WiFi Protected Setup)

 Easy Setup
World's most intuitive utility interface guides you to install a secured network in 3 steps

 Intelligent QoS
Prioritizes both wired and wireless Internet traffic to bandwidth-sensitive applications like online gaming, VoIP or stream multimedia




Technical Specifications

Hardware Features
Standards 802.11n, 802.11g, 802.11b, 802.3, 802.3u,802.3x
Band 2.4Ghz
Wireless Rate 300Mbps
Interface & Speed 1 10/100Mbps auto-negotiation Ethernet WAN Port
4 10/100Mbps auto-negotiation Ethernet LAN Ports
Button 1 WPS/Reset button
LED POWER/SYS/WPS/WLAN/LAN/WAN
Antenna 2*5dBi non-detachable antenna
Power 220V
9V==1A
Dimensions (LxWxH,mm) 172mm×110.2mm×31mm
Wireless Features
Basic Features Channel 13 channels
Channel Width 20Mhz, 20Mhz/40Mhz
Transmit Power B Mode:
1/2/5.5/11Mbps : 19dbm, +0.5dbm/-0.5dbm
g Mode:
6/9Mbps : 16dbm:+0.5dbm/-0.5dbm
12/18Mbps : 15.5dbm:+0.5dbm/-0.5dbm
24/36Mbps : 15dbm:+0.5dbm/-0.5dbm
48/54Mbps : 15dbm:+0.5dbm/-0.5dbm
n Mode:(Single antenna 20/40M)
MCS0/1_:7.2/15, 14.4/30 Mbps:16dbm: +0.5dbm/-0.5dbm
MCS2/3_:21.7/45, 28.9/60 Mbps:15.5dbm: +0.5dbm/-0.5dbm
MCS4/5_:43.3/90, 57.8/120 Mbps :15dbm: +0.5dbm/-0.5dbm
MCS6/7_:65/135, 72.2/150 Mbps :15dbm:+0.5dbm/-0.5dbm
Working Modes WDS
Wireless Security WPA-PSK,WPA2-PSK,WPA-PSK&WPA2-PSK
Software Features
Internet Connection Type PPPoE/Static IP/Dynamic IP/PPTP/L2TP
DHCP Built-in DHCP server
Security Port/MAC address/URL filter
Bandwidth Control Yes
DDNS Yes
Others
Operating Enviroment Operating Temperature 0℃ ~ 40℃
Storage Temperature -40oC ~ 70oC
Operating Humidity 10% ~ 90% RH non-condensing
Storage Humidity 10% ~ 90% RH non-condensing
Minimum System Requirement Computer with:
Internet Explorer 5.5 or Firefox 1.0 Higher
CD Drive
Network Adapter
Package Contents W308R Wireless-N Broadband Router
Power Adapter
Quick Installation Guide
One CD-ROM (User Guide and Setup Wizard included)
Certificates FCC ,CE ,RoHS,WEEE
