Asus ProArt PA24AC 24-inch, WUXGA Professional Monitor

Asus ProArt PA24AC 24-inch, WUXGA Professional Monitor
Asus ProArt PA24AC 24-inch, WUXGA Professional Monitor
24-inch WUXGA 1920 x 1200 IPS display with frameless design. 100% of sRGB color gamut, pre-calibrated for excellent color accuracy (ΔE < 2). Support HDR-10 presents HDR (High Dynamic Range) performance. ASUS ProArt Calibration technology offers advanced adjustments, including a 14-bit lookup table for color accuracy and 5 x 5 grid uniformity testing. I/O ports: DP over USB-C™ with 60W Power Delivery, DisplayPort, HDMI, USB 3.0 hub

Price:  29,990

Installment Promo! Easy Monthly Payments.

Pay only P 2,824 a Month for 12 months.

Or pay only P 5,348 a Month for 6 months.

  • Installment promo is available for locally issued credit cards
  • Card holder must transact inside an Asianic store to avail of the installment
Extreme clarity, superior contrast
ASUS ProArt™ PA24AC is Worldwide 1st 24-inch HDR400 with Thunderbolt™ 3 professional monitor. It features WQHD IPS panel with a 4-side frameless design and a wide 100% of sRGB color gamut. Up to 400 nits of brightness and HDR-10 provide lifelike experience. PA24AC features Thunderbolt™ 3 USB-C ports supports data transfers at up to 40 Gbps, DisplayPort and also support 45W power delivery. Advanced ProArt™ calibration technology and factory pre-calibrated to ensures the color accuracy (∆E < 2). With Windows- and Mac OS-certified, PA24AC is ideal for graphic designers, photographers, or anyone looking for high color accuracy.

Image result for Extreme clarity, superior contrast ASUS ProArt™ PA27AC is Worldwide 1st 27-inch HDR400 with Thunderbolt™ 3 professional monitor. It features WQHD IPS panel with a 4-side frameless design and a wide 100% of sRGB color gamut. Up to 400 nits of brightness and HDR-10 provide lifelike experience. PA27AC features Thunderbolt™ 3 USB-C ports supports data transfers at up to 40 Gbps, DisplayPort and also support 45W power delivery. Advanced ProArt™ calibration technology and factory pre-calibrated to ensures the color accuracy (∆E < 2). With Windows- and Mac OS-certified, PA27AC is ideal for graphic designers, photographers, or anyone looking for high color accuracy.

Impeccably detailed visuals
With 77% more pixels than conventional Full HD monitors, ProArt™ PA24AC offers WQHD (2560 x 1440) resolution for the superior picture quality and sharp imagery that photographers desire. And, with so much extra screen space, you can work more easily and comfortably with less scrolling and zooming.

Image result for Impeccably detailed visuals  With 77% more pixels than conventional Full HD monitors, ProArt™ PA27AC offers WQHD (2560 x 1440) resolution for the superior picture quality and sharp imagery that photographers desire. And, with so much extra screen space, you can work more easily and comfortably with less scrolling and zooming.


2K WQHD 2560 x 1440
Shows less detail and spacing with less room for work bars on the side PA24AC gives 77% more onscreen space than a similarly sized Full HD display

Image result for 77% More onscreen
Bring out the true beauty of your pictures
Achieving 100% coverage of the sRGB color gamut, ProArt PA24AC reproduces richer and more vivid colors, ensuring that colors in your photos look more lifelike.

Image result for Bring out the true beauty of your pictures  Achieving 100% coverage of the sRGB color gamut, ProArt PA27AC reproduces richer and more vivid colors, ensuring that colors in your photos look more lifelike.

A picture painted with extra colors
Ideal for photographers, graphic designers or anyone looking for high accuracy, PA24AC offers 8-bit color graphics to display over 16.7 million colors. It uses a 14-bit internal lookup table and supports Gamma values of 2.6, 2.4, 2.2, 2.0 and 1.8 to give you natural-looking images, and smoother transitions between hues.

A brighter, more lifelike viewing experience
ProArt PA24AC features up to 400 nits of brightness and HDR-10 high dynamic range technology for brighter whites and darker blacks, resulting in a rich and lifelike viewing experience.

High Dynamic Range

Related image

High color fidelity for truly expressive hues
Revel in pure, expressive hues thanks to accurate, true-to-life color reproduction. Each ProArt PA24AC monitor is pre-calibrated to guarantee industry-leading color accuracy (∆E < 2), and features ASUS advanced gray-scale tracking technology that provides a report of calibration levels 63, 127 and 255. This ensures your images are accurately reproduced onscreen, allowing you to see exactly how your work is going to look when it's finished. PA24AC also comes with 95% uniformity compensation to guard against brightness and chroma (color) fluctuations on different parts of the screen.

ASUS ProArt Calibration Technology
Whether you're using a desktop or laptop, PC or Mac, ASUS ProArt Calibration Technology offers color accuracy tuning and uniformity compensation to make things easy when it's time to recalibrate your display's brightness and color consistency.

Achieve optimum color accuracy when working with different types of content with a variety of advanced setups, allowing you to adjust color gamut, brightness, black levels, gamma correction, color temperature and uniformity.
  • Color Accuracy Optimization
  • Uniformity Compensation
  • Saved Color Parameter Profiles
  • Compatible with Most Calibrators

The port that does it all
For unrivaled expandability and versatile, ultrafast connections, ProArt PA24AC includes two USB-C ports that support Thunderbolt™ 3 for data transfer speeds of up to 40Gb/s, DisplayPort and USB 3.1 with Power Delivery for providing up to 45W of power to external devices. In addition, you can daisy-chain several displays through a single port without the need for a hub or a switch. With Thunderbolt™ 3, the possibilities are truly endless!

Image result for The port that does it all  For unrivaled expandability and versatile, ultrafast connections, ProArt PA27AC includes two USB-C ports that support Thunderbolt™ 3 for data transfer speeds of up to 40Gb/s, DisplayPort and USB 3.1 with Power Delivery for providing up to 45W of power to external devices. In addition, you can daisy-chain several displays through a single port without the need for a hub or a switch. With Thunderbolt™ 3, the possibilities are truly endless!

Picture-in-Picture & Picture-by-Picture
Built-in Picture-in-Picture (PiP) and Picture-by-Picture (PbP) functionality let you view content from multiple WQHD sources simultaneously and switch between them easily. You can even select which audio source to play.

Image result for The port that does it all  For unrivaled expandability and versatile, ultrafast connections, ProArt PA27AC includes two USB-C ports that support Thunderbolt™ 3 for data transfer speeds of up to 40Gb/s, DisplayPort and USB 3.1 with Power Delivery for providing up to 45W of power to external devices. In addition, you can daisy-chain several displays through a single port without the need for a hub or a switch. With Thunderbolt™ 3, the possibilities are truly endless!

Picture-by-Picture (PbP) mode
Place multiple input sources side by side onscreen and configure each individual window's color settings with sRGB, User Mode 1, and User Mode 2 to see the difference between them.

Picture-in-Picture (PiP)
Places your second input source in a window in one corner of the display.

Image result for Picture-by-Picture (PbP) mode Place multiple input sources side by side onscreen and configure each individual window's color settings with sRGB, User Mode 1, and User Mode 2 to see the difference between them.

QuickFit Virtual Scale
Save time and work smarter with ASUS QuickFit Virtual Scale. It provides you with an onscreen grid overlay so you can align and preview documents in their actual sizes prior to printing. There's also an intuitive 5-way navigation joystick so you can easily access and switch settings using the onscreen menu.

Image result for QuickFit Virtual Scale  Save time and work smarter with ASUS QuickFit Virtual Scale. It provides you with an onscreen grid overlay so you can align and preview documents in their actual sizes prior to printing. There's also an intuitive 5-way navigation joystick so you can easily access and switch settings using the onscreen menu.

Protect your eyes with ASUS Eye Care technology


ASUS blue light filter
ASUS Ultra-Low Blue Light technology is designed to protect viewers from harmful exposure to blue light. Certified by TÜV Rheinland, the blue light filter offers four settings that are easily accessed through the onscreen display menu via the hotkey.

  • Standard
  • Web Browsing
  • Viewing Photos and Videos
  • Reading or Word Processing
  • Viewing in Low Ambient Light

ASUS Flicker-free technology
ASUS Flicker-Free technology provides a more comfortable viewing experience and work environment by reducing onscreen flicker to minimize eye strain, headaches and eye fatigue when you spend long hours in front of the display.

Ergonomic Design
With ProArt PA24AC, a comfortable viewing position is always within reach thanks to its slim profile and ergonomically-designed stand with tilt, swivel, pivot, and height adjustments. Its onscreen menu even rotates automatically to display correctly when using the monitor in portrait orientation — handy when working with websites or longer documents.


Technical Specifications

Display
Panel Size : Wide Screen 24.1"(61.13cm) 16:10
Color Saturation : 100%(sRGB)
Panel Type : IPS
True Resolution : 1920x1200
Display Viewing Area(HxV) : 518.4 x 324 mm
Brightness : 350 cd/㎡ (Typical)/400 cd/㎡ (Peak)
Contrast Ratio : 1000 :1 (Typical)/8000 :1 (HDR)
ASUS Smart Contrast Ratio (ASCR): 100000000:1
Viewing Angle (CR≧10) : 178°(H)/178°(V)
Response Time : 5ms (Gray to Gray)
Display Colors : 16.7M (real 8 bit)
Flicker free : Yes
LCD ZBD Warranty : Yes
HDR (High Dynamic Range) Support : Yes

Video Feature
Trace Free Technology : Yes
SPLENDID Video Preset Modes : 8 Modes (sRGB Mode/Rec. 709 Mode/Scenery Mode/Standard Mode/
User Mode 1/User Mode 2/Reading Mode/Darkroom Mode)
Color Temperature Selection : 4 Modes
Color Accuracy : △E< 2
Gamma adjustment : Yes (Support Gamma 1.8/2.0/2.2/2.4/2.6 )
Color Adjustment : 6-axis adjustment(R,G,B,C,M,Y)
QuickFit (modes) : Yes (A4/B5/Alignment Grid/Ruler/Customization Modes)
Picture-in-Picture : Yes
Picture-by-Picture : Yes
Low Blue Light : Yes
HDCP support : Yes, 1.4 & 2.2
Adaptive-Sync supported : Yes

Audio Features
Stereo Speakers : 2W x 2 Stereo RMS

I/O Ports
Signal Input : HDMI(v2.0a) x2, DisplayPort 1.2, USB Type-C
Earphone jack : 3.5mm Mini-Jack
USB upstream : USB3.0 Type-C x1
USB downstream : USB3.0 Type-A x4

Signal Frequency
Digital Signal Frequency : 30 ~85 KHz (H) /48 ~70 Hz(V)

Power Consumption
Power On (Typical) : < 21W*
Power Saving Mode : < 0.5W ; Power Off Mode : 0W (Hard Switch)
100-240V, 50/60Hz
Mechanical Design
Chassis Colors : Gray
Tilt : -5°~+23°
Swivel : -45°~+45°
Pivot : -90°~+90°
Height Adjustment : 0~110 mm
VESA Wall Mounting : 100x100mm
Frameless Design : Yes
Quick Release Stand Design : Yes
Security : Kensington lock

Dimensions
Phys. Dimension with Stand (WxHxD) : 532 x (378-488) x 202 mm
Phys. Dimension
without Stand (WxHxD) : 532 x 349 x 55 mmBox Dimension (WxHxD) : 650 x 260 x 430 mm

Weight
Net Weight (Esti.) : 6.5 kg
Net Weight Without Stand (Esti.) : 4.28 kg
Gross Weight (Esti.) : 9 kg

Accessories : Power cord
DisplayPort cable
USB-C cable
USB-C to A cable
Quick start guide
HDMI cable
Warranty Card
Color pre-calibration report
Cable Clip
Compliance and Standards : Energy Star®, BSMI, CB, CCC, CE, CEL level , CU, ErP, FCC, ISO-9241-307,
J-MOSS, KCC, Mac Compliance, PSE, RoHS, TCO7.0, UkrSEPRO, UL/cUL, VCCI, WEEE, WHQL (Windows 10, Windows 8.1, Windows 7), MEPS, TUV Flicker-free , KC , eStandby, TUV Low Blue Light, Vietnam MEPS, ICES-3, RCM, VESA DisplayHDR 400
Note : *HDCP2.2 for HDMI and DisplayPort ports
*Adaptive-Sync for HDMI and DisplayPort ports
*HDR-10 by HDMI / DisplayPort ports. HDR performance requires
compatible monitors, streaming devices, video graphic cards, OS and
playback software for PC devices or media players which all support HDR function.
