Deepcool M3 Multi Color with 2.1 Subwoofer Cooler Pad
Features
High Cooling Performance & Super Sound
Shock Shape
The design of M3 tends to be more calm and powerful on its overall shape, which looks like a corner of the folded mountain, and the V-shaped metal mesh design on the top is also the embodiment of the concept. Meanwhile, M3 is for the first time using black and white as its packing color, the overall design with novel and classic collocation is inclined to casual.
Classic Collocation
M3 adopts HIPS high quality material with impact resistance, sturdy overall, with V-shaped metal mesh at the top. The mosaic fit not only reveals a perfect sound, but also makes M3 out of dull to overflow the spirituality. Meanwhile, classic black M3 carry standard 600mm black audio cable, M3 blue smooth sound, M3 orange storm, M3 green prairie and M3 purple dream carry standard 600mm white audio cable.
Five Colors Choice
As the first notebook cooler of high-quality sound in the industry, M3 endeavors to make everything excellence, M3 black classic, M3 blue smooth sound, M3 orange storm, M3 green prairie, M3 purple dream, bringing high-quality aural enjoyment, but also take into account the visual enjoyment of the perfect color.
2.1
Multimedia Audio Systems
It is the first computer
cooler which built-in 2.1 bass multimedia sound system in the industry,
the bass of the middle, the alto and high pitch of the both ends make
the perfect sound. M3 is not only a notebook cooler for cooling, but
brings more comfortable high-quality entertainment experience.
The
Magnetic Loudspeaker
In order to avoid magnetic
leakage damage to the notebook and human body, designers use the
magnetic loudspeaker with better security and better stability, less
magnetic leakage, small voice distortion
Micro
USB Port
M3 support the power adapter optionally,
the Micro USB port at side can be externally connect with the phone
which hold standard Micro USB (applicable for all of mainstream smart
phone currently). When the Micro USB and the standard 2.0 USB interface
connected to the PC power supply, the system will automatically
recognize one.
About
Damping Chamber
In order to reduce the impact of the
sound resonance for notebook, designers makes the damping chamber around
the main part of the M3 at both sides to minimize the treble acoustic
resonance, so that no harm to the notebook computer and the users.
Brushed
Aluminum Plate
A large area of black brushed
aluminum plate with the metal elements enhances M3's texture of black
classic.
Green
Materials
A large area of high quality environmental
protection silicone, not only gives good performance of anti-slip, but
also makes the M3 colorful.
Super Sound
M3 is the first notebook cooler with built-in 2.1 bass multimedia audio system in the industry, there are three speakers in the front, the bass in the middle, the alto and high pitch in the both ends, 3D surround, stereo sound quality, volume is free to adjust, audio can be identified by the system automatically without driving, and the transmission is also more convenient to retain the perfect acoustic sound.
External Power Supply
M3’s Built in 2.1 multimedia audio systems has three magnetic loudspeakers for supporting its high quality sound. In order to better play the multimedia audio system, it is recommended that optionally use of the Micro USB interface adapter (standard Micro USB is on sale mainstream smart phone charger) supply power.
Health Use
For most users’ habits, M3 put to use the design of 8 ° ergonomic supporting which takes care of the user's spine health, and providing a more comfortable angle for the user to enjoy the perfect entertainment experience.
High Cooling Performance
M3 using a leading 14CM big fan, 600±150 to 1100±10 % fan speed of strong wind to ensure its strong cooling performance. In the mean time, VAD vertical spoiler design and the design of the back of the large vents also ensure the M3 free of wind exchanged.
V.A.D Vertical Spoiler Design
The VAD vertical spoiler design is origin from DEEPCOOL which using the runway diversion groove. Comparing to traditional metal mesh, M3 VAD vertical spoiler design maximize the performance of heat exchange, of which the centralized wind directly to the laptop heat parts to ensure excellent heat dissipation.
Adjustable Speed with Switch-mode
In order to bring more quality of user experience, M3 put to use switch type of speed regulation, fan speed control by you, and it better meets the different needs of different users and different environments on the air flow and sound, achieved the most close of static enjoyment, but also free to switch and low-carbon.
Safety Use (anti-slip and the proper placement)
Whatever the M3 black classic of big brushed aluminum plate, or the M3 colorful version of large environmental protection silicone pad, can M3 guarantee the notebook secure as ever, moreover, the large anti-slip pad in the bottom ensure the notebook stable. In the same time, it guides user correctly placing notebook to prevent the notebook blocking speakers, which may affecting the volume and sound.
- 2.1-channel speakers & 2.1 multimedia audio systems with excellent sound;
- Build-in magnetic loudspeaker with two damping chamber in the main body to protect your notebook safety;
- The standard USB port and USB-powered for the most comfort in use;
- Integration of speaker and cooling design;
- Standard 3.5MM audio port, Plug and Play without drive makes more convenient;
- Fan speed is in the control of you which meet the multiple balance of quiet and air volume;
- M3 with fashion appearance offering five choices of M3 black classic, M3 blue smooth sound, M3 orange storm, M3 green prairie, M3 purple dream.
Technical Specifications
| Overall Dimension | 360X327X54mm |
| Fan Dimension | Φ140X15mm |
| Net Weight | 1100g |
| Bearing Type | Hydro Bearing |
| Rated Voltage | 5VDC |
| Operating Voltage | 4.5～5VDC |
| Started Voltage | 2.8VDC |
| Rated Current | 0.5±10%~1±10%A |
| Power Input | 2.5 to 5W |
| FAN Speed | 700±150-1100±10%RPM |
| MAX.Air Flow | 47.35CFM |
| Noise | 21dB(A) |
| Frequency Response | 180Hz~15KHz |
| Tweeter | 2inches(52mm)+2inches(52mm) |
| SubWoofer | 2.25inches(57mm) |
| Sensitivity | 450±50mV |
| Audio Adapter | 3.5mm |
| Antimagnetic Function | Available |
