Epson EB-S10 Corporate Multimedia Projector
Availability: Phased Out
Pay only P 1,891 a Month for 12 months.
Or pay only P 3,783 a Month for 6 months.
- 0% interest promo is available for locally issued credit cards
- Card holder must transact inside an Asianic store to avail of the 0% promo
Features
Epson is pleased to introduce the Epson EB-S10 3LCD Multimedia Projectors. Bright, stylish and compact, the EB-S10 delivers performance and reliability to business and education environments in style.
- Powerful 2,600 Lumens Brightness – All the power you need to create big, bold presentations and dazzling home theatre
- Stylish, Compact Design – Powerful enough to be used as an installation projector, light and compact enough to be used as a portable. The 8 series delivers a professional appearance however it is used.
- 1.35X Digital Zoom – Flexible placement for either desktop or installation usage.
- Front Exhaust – Directs hot exhaust air away from desktop users and their audience.
The Epson EB-S10 projector offers a stylish new design, and impressive performance. A powerful 2,600 lumens enables use in bright environments, and their wide variety of input options ensures compatibility with a broad range of multimedia input devices including computers, home theatre equipment and gaming consoles.
Powerful 2,600 lumens brightness
The new Epson EB-S10 delivers a bright 2,600 lumen image thanks to Epson’s
unique E-TORL lamp technology and efficient optical engine. This makes the
EB-S10 bright enough to be used as either an installation or desktop projector
in even the brightest of rooms, without the need to dim the lights or close the
curtains.
Stylish, Compact Design
With stylish flowing lines, and compact form, the Epson EB-S10 conveys an
attractive, professional appearance whether installed on a ceiling mount, or
used as a portable presentation tool. White colouring enables the projector to
blend unobtrusively with the ceiling when mounted, leaving the presentation room
appearing clean and professional.
USB Display Function
The Epson EB-S10 can display your presentation via a connection to a PC or Mac
with a simple USB cable.
1.35X Digital Zoom
The Epson EB-S10 boasts a 1.35x digital zoom ensuring flexible installation and
desktop use.
Technical Specifications
| PRODUCT TYPE | Entry Level Multimedia Projectors | |
|---|---|---|
| PRODUCT NAME | Epson EB-S10 | |
| PRODUCT CODE | V11H369053 | |
| PROJECTION SYSTEM | RGB Liquid Crystal Shutter Projection System | |
| PROJECTION METHOD | Front / Rear / Ceiling Mount | |
| SPECIFICATION OF MAIN PARTS | ||
| LCD | Size | 0.55 inches without MLA |
| Driving method | Poly-Silicon TFT Active Matrix | |
| Pixel number | 480,000 pixels (800 x 600) x 3 | |
| Native resolution | SVGA | |
| Aspect ratio | 4:3 | |
| Pixel arrangement | Cross Stripe | |
| Refresh Rate | 50Hz-60Hz | |
| PROJECTION LENS | Type | Digital zoom / Manual focus |
| F-number | 1.44 | |
| Focal length | 16.6mm | |
| Zoom ratio | 1.0 ~ 1.35 Digital | |
| LAMP | Type | 200W UHE |
| Life (estimated) | 5000Hr ( Low Brightness )# 4000Hr ( High Brightness )# | |
| #Subject to operation and environmental conditions. | ||
| OPTICAL SYSTEM | Dichroic Mirror Separation & Prism combine method | |
| SCREEN SIZE (PROJECTED DISTANCE) | 23 to 260 inch [0.87 to 10.5m]
(Zoom: Tele), 30 to 350 inch [0.87 to 10.5m] (Zoom: Wide) |
|
| LIGHT OUTPUT (Brightness) | ||
| Normal Mode | 2,600 Lumens Light Output 2,600 Lumens Colour Light Output (Colour mode: Dynamic, Zoom: Wide) |
|
| Eco Mode | 2,040 Lumens Light Output 2,040 Lumens Colour Light Output (Colour mode: Game, Zoom: Wide) |
|
| CONTRAST | 2000:1 (Auto Iris On) | |
| BRIGHTNESS UNIFORMITY | 90% (Typ.) | |
| COLOUR REPRODUCTIVITY | Full colour (16.77 million colours) | |
| VIDEO QUALITY | Simple Interlace-Progressive conversion | |
| SOUND OUTPUT | 1W monaural | |
| EFFECTIVE SCANNING FREQUENCY RANGE (ANALOG) | ||
| PIXEL CLOCK | 13.5MHz to 108MHz up to UXGA 60Hz | |
| HORIZONTAL | 15KHz to 69KHz | |
| VERTICAL | 50Hz to 85Hz | |
| ADJUSTMENT FUNCTION | ||
| PROJECTOR / REMOTE CONTROL | Brightness / Contrast / Tint / Saturation /
Sharpness / Input Signal Colour Temperature / Tracking / Position / Sharpness / Volume e.t.c. |
|
| FOOT ADJUSTER | Front-centre | |
| TILT ANGLE | 0 to 12 degrees | |
| AUTO KEYSTONE CORRECTION | Vertical: -30 to +30 degrees | |
| PASSWORD PROTECTED FUNCTION (security function) |
Implemented | |
| ANALOGUE RGB I/O | ||
| DISPLAY PERFORMANCE | Native | 800 x 600 pixels |
| INPUT SIGNAL | Signal type | Separate signal |
| Video signal | Analogue (0.7V p-p, 75ohm / Mac 0.714Vp-p, 75ohm) | |
| Sync. signal | Separate (positive & negative, bi-polarity 2-5 Vpp) / Composite (positive & negative, bi-polarity 2-5Vpp) / Sync-on-green (negative, 0.3Vpp) | |
| Audio signal | 500mVrms / 47K-ohm | |
| INPUT TERMINAL | Video | D-sub 15pin x 1 (Blue moulding) |
| Audio | RCA x 1 (White/Red) | |
| OUTPUT SIGNAL | Video | Analog (0.7Vpp, 75ohm / Mac 0.714Vpp, 75ohm) |
| Sync. | Separate (positive & negative,TTL) / Composite (positive & negative,TTL) / Sync. on green (negative 0.2 - 0.4Vpp) |
|
| OUTPUT TERMINAL | Video | D-sub 15pin x 1 (Blue moulding) |
| VIDEO I/O | ||
| DISPLAY PERFORMANCE | NTSC: 560 lines, PAL: 560 lines (Depends on observation of the multi burst pattern) | |
| INPUT SIGNAL | Video standard | NTSC / NTSC4.43 / PAL / M-PAL / N-PAL / PAL60 / SECAM |
| Video signal | Composite Video (1.0Vpp / Sync. negative, 75ohm) / S-Video (Luminous 0.714Vpp, Chrominous 0.286Vpp, 75ohm) / Component Video (Analog Y level 0.75V 75ohm / Cr Cb level +/-0.35V 75ohm / sync. negative 0.3V or 3-state+/-0.3V on Y) / Video-RGB (0.7Vpp, 75ohm / Mac 0.714Vpp, 75ohm) |
|
| Audio signal | 500mVrms / 47k-ohm | |
| INPUT TERMINAL | Video | Composite Video: RCA (Yellow) x1 S-Video: Mini DIN Component Video: D-sub 15pin (Blue moulding) |
| Audio | RCA x 2 (White/Red ) | |
| USB DISPLAY | ||
| Display Performance | 800 x 600 dots | |
| CONTROL I/O | ||
| USB I/O | Type B x 1 (for mouse control) | |
| OPERATING TEMPERATURE | 5°C to 35°C (41°F to 95°F) > (20%-80% Humidity ) | |
| COOL-DOWN PERIOD | "Instant off" | |
| START-UP PERIOD | Approx. 5 seconds (warm up 30 seconds) | |
| POWER SUPPLY VOLTAGE | 100-240V AC±10% 50/60Hz | |
| POWER CONSUMPTION | 100-240VAC 3.2-1.4A 50/60Hz
Lamp 280W/265W (Lamp on) 0.3W/0.4W (standby) |
|
| DIMENSION | ||
| EXCLUDE FEET | 228(D) x 295(W) x 77(H) mm | |
| MAXIMUM DIMENSION | 228(D) x 295(W) x 79(H) mm | |
| WEIGHT | Approx. 2.3kg | |
| FAN NOISE | ||
| ECO MODE | 29dB | |
| NORMAL MODE | 34dB | |
| WARRANTY | ||
| STANDARD WARRANTY | 1 years *excluding lamp |
|
| ACCESSORIES | ||
| POWER CORD | 1.8m | |
| COMPUTER CABLE | 1.8m, D-sub 15pin (Male) - Mini D-sub 15pin (Male) | |
| REMOTE CONTROL | Included | |
| SOFT CARRYING CASE | Included | |
| PASSWORD PROTECT STICKER | Included | |
| AIR FILTER | Included | |
| OWNER'S MANUAL | CD-ROM | |
| PRODUCT OPTIONS | ||
| Product Code | Item Code | Description |
| V13H010L54 | Lamp | |
| 7012083 | Ceiling mount with telescopic pole | |
| 7012084 | Ceiling mount standard | |
