Tenda 3G611R 150Mbps 3G 4 Port Wireless Router

Features

3G611R+ is a 802.11n compliant 3G router that allows users to access 3G networks. Simply insert a compatible UMTS/HSPA/EVDO USB adapter into the router to share your mobile broadband Internet connection through a secure, high-speed 802.11n wireless network. A 10/100 Ethernet WAN port allows you to access a DSL/Cable modem as the primary backup connection.

Equipped with one external 5dBi antennas, this router performs faster file transfers and farther coverage enabling greater wireless signals across your home. The 3G611R+ also includes a 4-port 10/100Mbps Ethernet switch for extra users.

In addition, the wireless adapter supports advanced WEP, WPA and WPA2 security modes that ensure you will be able to share files and surf Internet within a secured connection. The Wi-Fi Protected Setup? (WPS) feature enables devices to quickly establish a secure connection to an access point or wireless router, eliminating complex encryption codes.

This router is great for situations where an impromptu wireless network must be set up, or wherever conventional network access is available. It also can be installed on buses, trains, or boats, allowing passengers to check e-mail or chat online while commuting

Always Connected
Create instant WiFi hotspots at remote locations, virtually anywhere DSL and cable aren't available

Compatibility
Compatible with most major UMTS/HSPA/EVDO USB modems, over 150 types

Wired or Wireless Internet Access
Enables internet access through 3G wireless broadband networks, existing WiFi (WISP), or Ethernet -based data services ( Cable / DSL )

WiFi AS WAN
Receives a public WiFi signal and uses it to create internet access, allowing you to securely share among multiple users

N Speed
Delivers up to 150Mbps wireless speed, 4X faster than ordinary wireless G devices

Better Wireless Range
Coverage of up to 100 meters indoor  and 300 meters outdoor ,3X farther than ordinary wireless G devices

Advanced Security
Prevents unwanted access to connected computers with WPA/WPA2

Easy To Use
Connects all your WiFi enabled devices by simply plugging in your activated USB data modem

Technical Specifications

Hardware Features
Standards	802.11n, 802.11g, 802.11b, 802.3, 802.3u,802.1p
Band	2.4GHz
Wireless Rate	150Mbps
Interface	1 10/100M auto-negotiation RJ45 WAN port (Auto MDI/MDIX) 4 10/100M auto-negotiation RJ45 LAN ports (Auto MDI/MDIX)
Button	Reset
LED	3G Router/AP/Wireless Router/LAN/WAN/WPS
Antenna	Detachable 3dBi antenna
Power	AC 110~240V DC 12V 1.5A
Dimensions (LxWxH,mm)	190mm×122.2mm×32.9mm
Wireless Features
Basic Features	Channel	11 channels
	Channel Width	20Mhz, 40Mhz
	Transmit Power	Max. 20dbm
Working Modes	3G wireless Router, AP, wireless signal amplifier and wireless Router
Wireless Security	WEP,WPA-PSK,WPA2-PSK,WPA,WPA2
Software Features
Internet Connection Type	3G/ Dynamic/Static IP/PPPoE
DHCP	DHCP server
Security	LAN access control; MAC address-based access control; Built-in firewall; URL Monitor
Bandwidth Control	QoS (Quality of Service); WMM
DDNS	Yes
Others
Operating Enviroment	Operating Temperature	0℃ ~ 40℃
	Storage Temperature	-40oC ~ 70oC
	Operating Humidity	10% ~ 90% RH non-condensing
	Storage Humidity	5% ~ 90% RH non-condensing
Minimum System Requirement	Computer with: Internet Explorer 5.5 or Firefox 1.0 Higher CD Drive Network Adapter
Package Contents	3G611R+ 11N Wireless Router with Detachable Antenna Power Adapter Quick Installation Guide Software CD (User Guide included)
Certificates	FCC,RoHS,CE(Wireless),WEEE
