Tenda N6 Concurrent Dual Band Wireless IPTV Router

Tenda N6 Concurrent Dual Band Wireless IPTV Router
Tenda N6 Concurrent Dual Band Wireless IPTV Router
Simultaneous Dual-Band N (2.4 & 5 GHz) doubles your network bandwidth, Maximum wireless speed up to 300 + 300 Mbps, Best wireless signal coverage throughout your home, Quick to secure your network by pushing WPS button, Ideal for online gaming, streaming HD etc.
Price:  1,999

Features



The N6 is a concurrent dual band router that delivers a combined wireless speed of 600Mbps (300+300Mbps) on both 2.4GHz and 5.0GHz. It also provides superior coverage designed to reduce dead spots for users who look for higher wireless performance. Just connect the N6 to your DSL modem and provide a high speed wireless network for multiple users in a big house or office. Powered by dual band technology, it enables you to do simple tasks like emailing and surfing on 2.4GHz band. Meanwhile it avoids interference on 5.0GHz band, maximizing bandwidth ideal for bandwidth-intensive applications like HD media streaming, big-file transfer and wireless gaming. In addition, the N6 supports QoS feature that prioritizes time-sensitive online traffic, this router enables smooth Internet phone calls (VoIP) and responsive gaming.



Simultaneous Dual-Band N (2.4 & 5 GHz) doubles your network bandwidth
>> Maximum wireless speed up to 300 + 300 Mbps
>> Best wireless signal coverage throughout your home
>> Quick to secure your network by pushing WPS button
>> Ideal for online gaming, streaming HD etc.



The N6 runs both 2.4 and 5 GHz bands concurrently, providing a combined wireless speed of up to 600Mbps ( 300+ 300). So you can check your email, surf and chat on 2.4GHz while enjoy streaming HD videos, downloads, and online gaming simultaneously.



The router allows users to create multiple logically separated wireless networks. By creating such virtual networks, your wireless network is protected while allowing visiting guests to access to Internet temporarily.



The N6 supports IP QoS (Quality of Service), allowing optimum utilization of bandwidth and offering bandwidth control over congestion, preventing bandwidth abuse. In this way, users of a small network receive committed and specific bandwidth, preventing non-critical applications from degrading network performance.



Features with IPTV service, the N6 enables you to enjoy online videos on your TV set via a set-top box while surfing Internet and other online activities.



By utilizing Wireless Distribution System ( WDS) feature, N6 allows you to set up wireless communications between two or more routers, thus extending your wireless coverage to a farther distance. Any client devices within the range can easily connect to the network and access to Internet wirelessly.



Powered by the WiFi technology from leading chipmaker Broadcom, the N6 offers a more reliable and more stable wireless performance than others can do.


Features

Hardware Features
Standards 2.4GHz: IEEE802.11n, IEEE802.11g,IEEE 802.11b;
5.0GHz: IEEE 802.11n, IEEE 802.11a;
IEEE802.3, IEEE802.3u
Interface 1*10/100 WAN port;
3*10/100 LAN ports;
1*10/100 IPTV port (function as a LAN port with IPTV disabled)
Antenna 2* 5dBi fixed external omni-directional dual-band antennas
Button 1* WPS; 1* Reset
Power Input: AC 100-240V~50/60Hz 0.3A;
Output: DC 9V1A.
Temperature Operating Humidity: 0℃ ~ 40℃;
Storage Temperature: -40℃ ~ 70℃.
Humidity Operating Humidity:10% ~ 90% RH non-condensing;
Storage Humidity: 5% ~ 90%RH non-condensing.

Dimensions (L*W*H) mm 172mm*111mm*25mm
LED 1*Power, 1*SYS, 1*WPS, 1*5G, 1*2.4G, 3*LAN, 1*IPTV, 1*WAN
Wireless Features
Wireless Speed 2.4GHz: 300Mbps;
5GHz: 300Mbps.
Frequency Works over both 2.4GHz and 5GHz bands
Basic Features Wireless:Enable/Disable;
SSID Broadcast: Enable/Disable;
Band: 2.4GHz, 5GHz;
Channel-2.4GHz: 1-13;
Channel-5GHz: 149, 153, 157, 161, 165;
Network Mode-2.4GHz: 11b/g/n mixed (default mode),11b/g mixed, 11b, 11g;
Network Mode-5GHz: 11a/n mixed (default mode),11a;
Connection List.
Security Wireless MAC Address Filter (Wireless Access Control);
WEP, WPA-PSK/WPA2-PSK, WPA/WPA2;
Wireless Security: Enable/Disable;
WPS fast encryption.
Software Features
Internet Connection Type PPPoE;
Dynamic IP;
Static IP.
Operating Mode Wireless Router Mode;
WAP (wireless AP) Mode;
WDS Mode.
DHCP Server DHCP Server;
DHCP Client List;
DHCP Reservation.
Virtual Server Port Forwarding;
DMZ Host;
UPnP.
Security Client Filter,
MAC Filter,
Website Filter,
Remote Web Management
DDNS Yes
VPN Passthrough Yes
Other features Bandwidth Control;
IPTV capable;
Guest Network;
MAC Clone;
Traffic Statistics;
Backup & Restore configurations;
Firmware upgradeable via browser.
Others
Package Contents N6
Power Adapter
Quick Install Guide
Resource CD
Temperature Operating Temperature: 0℃ ~ 40℃;
Storage Temperature: -40℃ ~ 70℃.
Humidity Operating Humidity:10% ~ 90% RH non-condensing;
Storage Humidity: 5% ~ 90%RH non-condensing.
Factory Defaul Settings IP Address: 192.168.0.1
Login User name/Password: admin/admin
Related Products W522U Wireless N600 Dual-band USB Adapter
N60 Wireless N600 Concurrent Dual-band Gigabit Router
N80 Wireless N900 Concurrent Dual-band Gigabit Router
Certificates CE, FCC, RoHS
